Plb duct pipes

Leading Manufacturer of HDPE PLB Duct Pipes

BERLIA PIPES manufactures PLB Duct Pipes from High Density Poly Ethylene (HDPE) that are coated inside with silicon for permanent lubrication, aiding in easy installation as conduits for underground cabling. These pipes are produced at our state-of-the-art extrusion plants as per DOT Specification GR/CDS-08/02 Nov. 2004 amendments.

PLB Pipes are used as underground cable conduits for optical fiber cables, communication cables, etc., and are suitable for cable installation by blowing or pulling by rope techniques.

'BERLIA PIPES' was among the very first manufacturers to acquire the technology and equipment for establishing a complete manufacturing facility for PLB-HDPE Ducts.

At BERLIA PIPES, PLB Pipes (duct pipes) are manufactured using an ultra-violet (UV) stabilized grade of HDPE with required Anti-Oxidant content and other recommended additives. The inner layer of ducts is duly silicon coated, which minimizes friction between the OFC and the duct during the cable blowing process, enabling smooth installation of OFC in the duct without damaging the cable fibres.

Berlia PLB Duct Pipes are engineered for superior performance and safety. Designed to be anti-rodent, these pipes ensure durability by resisting damage from pests. Additionally, they are non-flammable and fire-retardant, providing an extra layer of safety in critical installations. Choose Berlia for reliable and secure piping solutions.

Features

  • Environment Stress Crack Resistance (ESCR)
  • Impact Resistance
  • Crush Resistance
  • Low Coefficient of Friction
  • High Temperature Resistance
  • High Ultraviolet (UV) protection

Sizes Available
  • 40/33 mm
  • 32/26 mm
  • 50/42 mm
  • 63/50 mm
Applications
COM-line Ducts are suitable for installation in the field dirt trenches, under sidewalks, roads, within communication networks, between communication centers and between cities. They can also be used in branch networks between cells, distribution cabinets, poles, in walls and within subterranean networks of homes, allowing the insertion of communication cables-optical or copper, as well as TV/cable aluminum coaxial cables. Cables can be inserted in through the pipe by blowing, with an internal air-pressure up to eight bars.

Note : All the specifications provided for PLB Duct pipes are as per TEC Specifications (BSNL/DOT).
